Models 6920/35
Continuous Form
Laser Printers


Designed for industrial-strength printing. Our new 6920 and 6935 continuous forms laser (CFL) printers combine the print quality and speed of laser technology with the advantages of continuous forms. Run your big print jobs—unattended—with complete confidence. Their inherent flexibility in 6920_35.gif (28513 bytes) handling forms—from 7 to 17.5 inches wide—and pinpoint accurate registration make the 6920/35 ideal for a wide variety of applications. Add superior reliability, outstanding support, and midrange systems expertise and you have an incredible, cost effective printing solution. (Click on picture for specifications)

Highlights

bulletPrecise continuous forms control
bullet20 ppm or 35 ppm
bulletEnables long, unattended print runs
bulletHigh duty cycle—200,000 to 300,000 pages/month
bulletTwinax/Coax/RS 232/RS422
bulletToll-free technical support
bulletComplete compatibility
bulletIGP/PGL, IGP/VGL, PCL5, IPDS

Advantages and Benefits

The 6920/35 printers provide unusually sharp print images on a wide range of fan-folded materials including data processing reports, invoices, and custom labels. Automatic job separation, combined with an optional power stacker, ensures unattended printing as well as zero forms waste. Run large print jobs—unattended—with assurance. A straight-through paper path combined with the power stacker option enables printing and stacking of an entire box of continuous forms without supervision or intervention.

Click here to go to Information Request Form

Flash Fusing Imaging System

DD 6920/35 CFL printers include a flash fusing imaging system that handles a very wide range of paper and label stock, including plastic cards and other synthetics. This Flash Fusing technology uses neither heat nor pressure to fuse its toner.

Wide Range of Applications

Customers can use the 6920 or 6935 for a wide variety of applications—from mailing labels for printing and publishing to drum labels for chemicals, from window stickers for automobiles to shipping and hanging labels for apparel, from shelf labels in grocery stores to mylar product labels for appliances and customer statements and bills for banks or utilities. The list is only limited by a user’s imagination.DOCS.gif (47664 bytes)

• Manufacturing
• Warehousing & shipping
• Retail
• Transportation
• Financial services
• Utilities
• Business services
• Medical

Pinpoint Registration Accuracy

Applications with tight registration requirements are a natural for our CFL printers. The precision pin feed drive design offers superior accuracy. With the 6920 or 6935, continuous forms are always in the exact right position for printing each and every time. This makes applications that demand precise print placement and no paper skewing perfect for these accurate printers.

Compatibility, PSA and Investment Protection

The 6920 and 6935 are compatible with existing forms for smooth operation. Existing applications can be used with little or no program changes.

In fact, these printers are at home in almost any IBM computing environment—from AS/400 Twinax to networks and client/server to mainframe Coax. In addition, our CFL printers include PSA (Printronix System Architecture). PSA enables any print application to operate on a plug and play basis across all DD CFL printers, DD and IBM line printers, or any Printronix printer. They are designed to permit the migration of applications among print technologies—line matrix, laser, or thermal transfer. These features along with their versatility make our CFL printers a very wise investment, offering protection should your business or printing needs change.

Wide Range of Printer Languages and Windows Supported

These printers support industry standard printing languages such as Printronix Graphics Language (IGP/PGL), Code V (IGP/VGL), Printronix LinePrinter Plus, IPDS, and PCL5. This language support makes it easy to develop and run printing applications to meet most needs. Moreover, these printers are specially designed to take advantage of the Windows environment. Special Windows print drivers deliver top performance from these printers. The result—our 6920/35 products bring industrial strength printing to Windows applications with ease.

The Decision Data Advantage

Decision Data is ISO 9001 certified and widely recognized for its high-quality, cost-effective midrange solutions. In fact, we’ve won an unequaled 37 Buyers’ Choice and Product Excellence awards since 1990.

With Decision Data continuous forms laser solutions, you get a quality product, backed by a superior warranty, and support from our toll-free Technical Assistance Center (TAC). You also get the added benefit of nearly 30 years midrange systems experience.

Model 6920

The 6920 is an industrial strength continuous forms laser printer which can handle continuous forms up to 17.5 inches wide with extraordinary ease at up to 20 pages per minute (PPM). The 6920 provides unusually sharp print images on a wide range of fan-folded materials including data processing reports, invoices, and custom labels. Automatic job separation, combined with an optional power stacker, ensures unattended printing as well as zero forms waste.

Model 6935

The 6935 is a top-of-the line CFL with extraordinary print quality which can handle

continuous forms up to 17.5 inches wide with extraordinary ease at up to 35 pages per minute (PPM). It’s optional cut sheet feature even enables on-the-fly switching between cut sheet and continuous forms printing under host computer control. Automatic job separation, combined with our intelligent power stacker, ensures zero forms waste on documents like checks, invoices, and custom labels.

The 6935 uses a unique 2-step fusing process. As the media passes through, its pores are opened by the warmth of halogen lamps. Next, as the toner is distributed onto the media, it is permanently bonded as Xenon lamps melt the toner deep into the pores of the media well beneath the surface.

Models 6920/35 Continuous Forms Laser Printers

The 6920/35 provide unusually sharp print images on a wide range of fan-folded materials including data processing reports, invoices, and custom labels.

Forms Size Flexibility

DD 6920 and 6935 printers offer extraordinary flexibility when it comes to forms size. They can handle forms from 7 inches to 17.5 inches wide and from 1 inch to 99 inches long. Moreover, 6920 and 6935 continuous forms are physically compatible with those used by line printers.

Specifications

Model Number 6920 6935
Printing Speed  up to 20 ppm (8.5" x 11" pg) up to 35 ppm (8.5" x 11" pg)
Duty Cycle (pages per month) 200,000 300,000
Technology Flash Fusion Durafusion Flash Fusion Durafusion
Warm Up Less than 60 seconds Less than 60 seconds
Toner  Dual component, dry 25K pages/cartridge at 4% print density (A4 or letter size) Dual component, dry 25K pages/cartridge at 4% print density (A4 or letter size)
Paper & Printing Specifications
Continuous Forms One part, tractor feed Min/max form width 7" to 16" 7" to 16" Optional max. width 17.5" 17.5" Min/max form width 7" to 16" 7" to 16" Optional max. width 17.5" 17.5"
Cut Sheet Forms Sizes Simplex only, A3, A4, Letter, B4, Ledger, Legal
Weight Bond
Card/Label stock
68 to 165 g/m2 (18 to 44 lbs)
up to 204 g/m2 (up to 125 lbs)
64 to 166 g/m2 (17 to 44 lbs)
up to 262 g/m2 (up to 125 lbs)
Printable Area Print line length 6" to 14.7" 6" to 14.6"
Print form length  +/-. .33" from perf .33" from perf
Type Media Electrostatic laser quality paper Electrostatic laser quality paper

Pressure sensitive laser labels
Synthetics
Plastic card
Media Handling Automatic
    job separation
Optional power stacker

Yes
Yes
Yes
Yes

Yes
Yes
Yes
Yes
Yes

Yes

Power stacker paper length

7" to 12" 7" to 12"
Input trays 500 sheet (A4, Letter)
250 sheet (A3, A4, B4, letter, ledger or legal)
500 sheet (A4, Letter)
250 sheet (A3, A4, B4, letter, ledger or legal)
Output trays 250 sheet 250 sheet
Configurations
Memory Standard 20 MB
Optional 128 MB
Standard 6 MB
Optional 24MB
Resolution Standard 300 x 300 dpi
Optional 240 x 240, 400 x 400 dpi
Standard 300 x 300 dpi
Optional 240 x 240, 400 x 400 dpi
Emulations  LinePrinter Plus IGP/PGL, IGP/VGL, PhoenixPage PCL5, IPDS LinePrinter Plus IGP/PGL, IGP/VGL, PhoenixPage PCL5, IPDS
Interfaces Twinax, Ethernet  RS232, RS242, Centronics Coax, Twinax, Ethernet RS232, RS242, Centronics Coax,
Physical Characteristics
Power
Line Voltage Frequency
200—240 Auto Range 47-62Hz
Line Voltage Frequency
200/220/240 50Hz/60 Hz
Power Consumption Printing / Standby
2.94 KVA /  0.3 KVA
Printing / Standby
4.3 KVA 0.5 KVA
Environmental Characteristics 10k BTU/hr. when printing 10k BTU/hr. when printing
Temperature 50° F—86° F 50° F—86° F
Humidity 30%—80% 30%—80%
Acoustic Noise 60 dBA 60 dBA
Max. Altitude 7500 Ft.  7500 Ft.
Dimensions
Printer
Printer with Stacker
48"H x 30"W x 34"D
48"H x 30"W x 42"D
47.5"H x 50.6"W x 36.8"D
47.5"H x 50.6"W x 36.8"D
Weight
Printer only
Stacker only
353 lbs.
125 lbs
442 lbs.
500 lbs.


Click here to go to Information Request Form

Specifications are subject to change.
