Overview

The e-TwinPrint Protocol Converter lets Twinax Printers Run Over TCP/IP to you iSeries or AS/400

Now workhorse Twinax printers (SCS and IPDS) printers in can be easily supported over your corporate LAN/WAN/VPN.

Protect your Twinax printer investment, even as you move the rest of your organization to a LAN environment.

Simple configuration and management is done using a standard Web Browser.  The e-TwinPrint is upgradeable to support  3- or 14-devices, giving it the full capabilities of the only pure TCP/IP remote controller, the e-Twinax Controller with support for not only printers, but Twinax display devices.

The e-TwinPrint creates the configuration on the host AS400 or iSeries for you using Remote Commands.  There is no need for your to create the device.  This is especially helpful when configuring AFP/IPDS printers. It automatically selects the proper PSF/400 parameters for you.  Just plug your Twinax printer into the e-TwinPrint and connect it to your Ethernet network with a CAT5 cable and you can run your Twinax printers over TCP/IP while retaining all the functionality of a Twinax printer - error reporting, page range printing, etc.

Rear view of e-TwinPrint with 2-port Twinax Y-Cable

The BOS e-TwinPrint provides several benefits:

• Web-managed configuration and management. Unlike others that require a PC with configuration and management software to be installed on the same LAN, the e-TwinPrint can be managed remotely over the Web. This permits IT staff to handle problems directly, without having to talk an end user on location through complex diagnostics.

• Dumb Terminal Setup. Initial setup can be performed with a dumb terminal, an advantage when the device is located in a small remote site without a PC.

• IPDS Printing. With the e-TwinPrint, the remote command service is used to create and maintain the IPDS printer device description on the host.

• SCS Printing. The e-TwinPrint implements TN5250e technology to provide support for all SCS printers.

• Upgradeable. The e-TwinPrint can be upgraded via a software key to support 3 or 10 devices Twinax devices (click here for more information on these upgraded capabilities)
