Wireless Model Number |
Operating System |
|
AR9170W11 |
Win11 IoT (Internet of Things) |
|
AR9170LX64 |
64-Bit Linux |
The
AR9100 is
a universal hardware platform with universal image support for
Windows 11 Internet of Things (Win11 IoT)
or Linux out of the
box. Citrix, Microsoft, VMWare, Quest and CLI TermPro
Terminal Emulation clients are all
standard. CLI's Device Manager software
is included with each device, making simple and
powerful management a reality. The AR9100 combines
strong power, performance and flexibility while
maintaining efficient power consumption.
If all you are looking for is an Ethernet "Dumb Terminal" and need a Parallel Port, we have CLI legacy Thin Client models that can be configured to act as a "Dumb Ethernet Terminal" just like the legendary ET2000. They can be configured to automatically boot up to a 5250 or 3270 sign-on screen. Click here to be taken to the IA8600 Thin Client Terminal page.
Featured Highlights
- Ruggedized Fanless Aluminum Form Factor
- AMD R2314 Quad-Core 2.1/3.5GHz Processor
- AMD Ryzen™ Embedded
- AMD Radeon™ Vega 6 Integrated Graphics
- Triple 4K Video
- 2 HDMI ports
- 2 DisplayPort 1.4 ports
- CLI DevMan Management
- Optional 122-key Keyboard to provide "no re-training" required migration to Ethernet connectivity from legacy "green screen" Twinax and Coax Terminals.
Click on the image above for a larger picture of
the 122-Key Keyboard
Click here for more information on the CLI
AR9100
Thin ClientTerminal
For Complete Specifications
Download the
AR9100 Datasheet
AR9100 Hardware Specifications
|
FEATURES |
DESCRIPTION |
AR9100W11 |
AR9100LX64 |
|
Operating System |
Customize your AR9100 with Windows 11 Internet of thinks (Win11 IoT) or 64-Bit Linux Operating Systems. |
WIN11 IoT |
Linux 64-Bit |
|
Processor |
AMD R2314 Quad-Core 2.1/3.5GHz
Processor |
||
|
Chipset |
AMD A-Series |
||
|
Video |
AMD Radeon™ Vega 6 Integrated Graphics |
||
|
Flash |
SATA SSD Flash Module |
32GB |
|
|
Memory |
(1) DDR3L -1333 SODIMM |
4GB |
|
|
Communications |
(2) Gigabit Ethernet Port |
||
|
Wireless |
Optional Integrated Mini PCIe Internal Wireless 802.11b/g/n Wi-FiTM with Dual Internal Antenna |
AR9170W11 |
AR9170LX64 |
|
CLI TermPro Terminal Emulation |
Supports TN5250 (IBM AS/400), TN3270, (IBM Mainframe), VT100, Wyse 60 and other ASCII (Unix/Linux Systems). Emulation Sessions with One or More Hosts Enhanced User Interface (TN5250 Display Only) Support for 122-Key keyboard, & TCP/IP (TN5250 and TN3270). |
||
|
Video Ports |
DVI-I, (1) RJ-45/Ethernet, (1) Mic-In Jack, (1) Audio Out Jack, (1) Micro SD Card Reader |
||
|
Ports and Connectors |
(2) USB 2.0 Ports (Rear). (3) USB
3.0 Ports (2 Front, 1 Rear) |
||
|
Mounting Hardware |
Standard: VESA 100mm Compliant Mounting Holes (Mounting Screws Included), Vertical Stand, Horizontal Feet. |
||
|
Power Supply |
Auto Sensing 100 - 240 VAC, 50/60Hz, Max 15 Watt |
||
|
Protocols |
Microsoft RDC/RemoteFX, Citrix ICA/HDX, VMware Horizon View, Web Browser, Telnet, TCP/IP with DNS, XDMCP, DHCP, PPP, and PXE |
||
|
Remote Management |
Device Manager Remote Configuration, Image Updates, Asset Management, Shadowing (License Purchase Required), Image Update and Recovery with USB Drive Supported |
||
|
Weight |
1.7 lbs |
||
|
Dimensions |
(w x d x h) 8.2 in x 5.7 in x 1.4 in |
||
|
Termperature & Humidity |
5 ?C to 40 ?C 20% to 80% Non-Condensing Humidity |
||
|
Safety Certifications |
RoHS, FCC Class B, VCCI, UL, CE |
||
|
Warranty |
Limited Three Year Hardware
Warranty |
||
For Complete Specifications
Download the
AR9100 Datasheet
Purchase On-Line - Call for Pricing
